Today we’re going to take a look at DJI PHANTOM 3 PROFESSIONAL.
- Flight time: Approx. 25 minutes
- Flight range:(1)Vertical: ±0.5 m
- Camera: Sensor 1/2.3” CMOS
- Effective pixels:12 M
- Lens:FOV 94° 20 mm (35 mm format equivalent) f/2.8
- ISO Range: 100-3200 (video)
- Electronic Shutter Speed: 8 – 1/8000 s
- Image Size: 4000×3000
- Still Photography Modes: Single Shot
Burst Shooting: 3/5/7 frames
Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias
- Video Recording Modes :FHD: 1920x1080p 24/25/30
HD: 1280x720p 24/25/30/48/50/60
- Max Video Bitrate: 40 Mbps
- Supported File Systems: FAT32 (≤32 GB); exFAT (>32 GB)
- Photo: JPEG, DNG (RAW)
- Video: MP4, MOV (MPEG-4 AVC/H.264)
- Supported SD Cards: Micro SD Card 8 GB included
- Operating Temperature Range: 32° to 104°F (0° to 40°C)
- Size: 590 mm
- Weight: 365 g
- Transmitter Power: FCC: 20 dBm CE: 16 dBm
- Battery type: 4480 mAh LiPo 4S
- Battery replaceable: Replaceable
- Charge time: 40 to 50 minutes
- Flight time: 25 minutes
- GPS positioning: N/A
- microSD support: N/A
- Distance: about 4,500 feet
- Good camera options
- Easy to fly and hovers very well
- Fast GPS internal processing
- Lightbridge connection to smartphone
- easy to set up,
- simple to fly
- stabilised camera shoots beautiful 4K footage.
- It is expensive
- hard to distinguish 4K footage from 1080p
- No obstacle avoidance technology
- Cannot live broadcast video
- Problem with fine scene details
- Only record from forward view
The most important feature of any drone is that you can trust it will follow your commands once you put it in the air. A computer and a drone can both crash, but only one will fall out of the sky. The DJI Phantom 3 Professional drone is the one you can make use of for a longer period without experiencing any erratic or buggy behavior. In fact, the first thing you’ll notice about the drone is how rock solid its positioning is. Most drones use GPS satellites to find and hold their place, but DJI has added the ability to work with GLONASS, a Russian counterpart to GPS. This means the P3 finds more satellites, and finds them faster, all of which translates into terrific performance.
When you can’t find a satellite signal (like when flying indoors), the P3 uses a visual positioning system enabled by a downward-facing camera. This feature, which first appeared on the more expensive Inspire 1, works well when the conditions are right. If you’re flying over a surface with good contrast, say a checkerboard tile floor, the P3 is quite stable, and will return to position when pushed. If you’re flying over a surface with a uniform color and texture, maybe a white linoleum floor, there isn’t much for the system to see, and it doesn’t work well.
Getting the most out of your position systems requires calibrating the compass whenever you arrive at a new location. You need to do an odd little “compass dance,” spinning the drone 360 degrees on its X and Y axes. Sometimes this worked right away, other times it failed to calibrate after several tries, warning me that there might be electromagnetic radiation about, and forcing me to repeat the whirling dervish act.
When all (or even some) of those positioning systems are working, the P3 feels a bit like magic. It goes where you tell it and doesn’t waver. The phantom 3 professional gives great 4K video in all different kinds of light and crisp 12 megapixel still images. If you leave the drone to hover, the video looks as though it was captured on a tripod, even when you’re several hundred feet in the air with moderate winds. The only drawback of the incredible stabilization is that when you rotate the drone horizontally, or pan the camera, the footage has a strange, stilted quality. This is a category-wide problem, although hopeful that the Solo, from 3D Robotics, will solve it by building in what Hollywood folks call “easing.”
The battery life on the P3 was a nice improvement over its predecessor. It routinely goes 20-25 minutes of flight time, versus the 15-20 minutes you get on the Vision 2+. The upgraded battery means this unit is not compatible with older versions of the drone or charger, and vice versa, which hurts if you already shelled out for extra batteries on previous Phantoms. And you only get one battery with your purchase. It takes 40 to 50 minutes to get a full charge, and the charger can now power up your battery and remote control at the same time.
The remote control now has an advanced video downlink system integrated directly inside, called LightBridge. That means an accessory which the company still sells for $1,400 now comes standard on a $999 drone. It also means you no longer need to worry about having the external Wi-Fi extender, which you needed to charge separately and clip onto the previous remote. That’s a big improvement, simplifying the amount of gear and preparation required. You don’t need a mobile device to fly the drone — it works with radio signals — but to really get anything out of it you will want to attach a phone or tablet to your remote using a USB connection and fire up the app.
The LightBridge also extends the range at which your mobile device can receive a live video feed of what the drone’s camera is seeing. users are expected to get roughly 4,500 feet, and in videos posted online, users show flights that clock in at three miles. Technically, you can still control the drone once you’ve lost a visual. The LightBridge brings a couple more cool new features to the P3. It lets you cache video on your mobile device while you’re still in the air, meaning you could fly into a volcano and still have the footage if your drone took an accidental lava bath. You can even edit and share video from inside the app while your drone is still in the air. All this leads us to the marquee new feature that LightBridge enables: live streaming.
You can broadcast from the app to YouTube or Youku, the Chinese equivalent. It doesn’t work very well over LTE, and sometimes performs well over Wi-Fi, while sputtering out on the same network during the next attempt. Originally it had both audio and video, but after an update this week DJI removed audio, an attempt to improve performance, but one that removes a lot of the fun and capability from the broadcaster.
The P3 has several features that are now industry standard, like takeoff and landing with the push of a button or swipe inside the app. You will find out that it never had trouble navigating a safe landing, even in tall grass. There is also a return to home function that will bring the drone back to where it took off or to the spot where your controller is currently located. This is the kind of feature that is crucial for beginners. If you lose sight of your drone or are feeling nervous, press the button and it will move toward an altitude of around 100 feet while heading back in your direction. You will also find out that it usually landed within four to five feet of where it started. You can interrupt it at any time to regain control of the drone.
DJI Phantom 3 Professional: Packaging
- Aircraft body
- Remote controller × 1
- Propeller paired × 4
- Intelligent Flight Battery × 1
- Battery charger × 1
- Battery Cable × 1
- Gimbal Clamp × 1
- Vibration Absorbers × 4
- 16GB micro SD Card × 1
- Micro USB Cable × 1
- Anti-Drop kit × 1
- Landing Pads × 4
- Propeller wrench ×1
- Stickers × 5 (Gold, Pink, Silver, Red, Blue)
DJI Phantom 3 Professional: Design
The Phantom 3 looks pretty much identical to DJI’s previous Phantom models: a stout white plastic body, four rotors and narrow, fixed landing legs slung beneath. It’s light enough to carry in one hand and, when you unscrew the rotor blades, it’s just about small enough to fit into a decent-sized backpack. It’s certainly more portable than the much larger Inspire 1 drone.
It feels as well built as before, with the capacity to survive both the odd bump into a wall or a small crash while you’re getting the hang of flying it. It can manage to fly it straight into the roof of my house where it plummeted three storeys to the grass below. Aside from a few cosmetic scuffs, it was absolutely fine, and continues to fly without any trouble.
The rotor blades are easily replaceable if you snap a few. Just unscrew them from the motors on each of the drone’s four corners. You’ll know how to do it already, since the blades are the only parts you need to assemble out of the box.
DJI Phantom 3 Professional: Camera
After a couple of flights, something interestin becomes apparent. Most people know DJI as drone company, but it’s also in the camera game (via stabilizers and other rigs, as well as flying cameras). On the Vision series, the shooters were okay, but utilitarian, forgettable. The Inspire 1 was when DJI started upping its game, and this trend carrie over to the Phantom 3 with its 4K/12-megapixel offering (for those interested, the sensor is a 1/2.3″ Sony Exmor). The more I flew, it started to become obvious that, if anything, the drone is almost secondary. Flying is fairly easy, and fun in and of itself, but getting a great photo or video is so much more rewarding.
It really helps that, in the Phantom 3’s camera, DJI has eliminated nearly every pain point that plagued the Vision series. I already mentioned the landing gear has been widened to prevent it from getting in shot. It further help with this, the camera now has a narrower field of view — 94 degrees, down from 140 (with a 35mm-equivalent focal length of 20mm and infinite focus). One bugbear remains, though, which is that it’s still easy to get the propellers in shot when flying forward at speed — but that’s a harder problem to solve. The Phantom 3’s FOV also helps with something else: fisheye distortion. The Phantom 3 barely has any.
For the technical fans, DJI tells me this is because “it is a 9-element rectilinear lens which is designed specifically for aerial and long distance shooting.” This is also why the close up focus isn’t so good (see samples in the gallery), it was designed for aerial, and not general purpose. The color balance also seems much improved from the Vision+, and the gimbal it hangs from keeps it steady as a rock. When you factor in a bunch of new shooting modes (burst, time-lapse, etc.) and manual exposure settings (via that app), you’ve got a really comprehensive photography tool.
DJI Phantom 3 Professional: Battery & Flight Time
One of the most popular drones currently on the market, the DJI Phantom 3 is the upgraded version of the DJI Phantom 2 . Celebrated for its ability to capture stunning images and videos, the Phantom 3 is also easy to maneuver and represents DJI’s “flagship consumer model.”
LED Light Bar
The Phantom 3 proprietary battery pack features a LED light bar for indicating when the battery is charging and discharging. The battery pack easily slides and clips into the back end of the Phantom 3.
Battery Capacity, Charging Time, Flight Time
This Phantom battery has a capacity of 5200mAh. Charging takes a little over an hour. An optional 12VDC charge cable is available should you want to charge the battery in your vehicle or with another 12VDC portable source.
The drone offers about 25 minutes of flight time. This is compared to 10 to 15 minutes of flight time with the Phantom 1 and 20 to 25 minutes with the Phantom 3.
A “Smart” Battery
The Phantom 3’s battery is hailed as “smart” because it processes charging, protection, and more through its motherboard. If you forget to turn off the quadcopter, the battery turns off by itself following 10 minutes of no use. If the battery gets too cold or hot, it will stop charging. Additionally, this “smart” battery sends authenticity codes to the Naza P2V. The Naza stops the motors from “arming” should it not receive the juice it needs from the battery.
DJI Phantom 3 Professional: Controller
The hand controller is not a cheap plastic module you typically get with a starter drone kit. This controller has rubber surfaces and is very comfortable to hold. It doesn’t feel like it’s about to slip out of your hands.
On the controller, you have a button for taking videos and for taking still images. You can also change your imaging exposure, and a dial what controls the pitch movements on the camera gimbal. Also, there are two customizable buttons on the back of the controller that you can configure. If you don’t like the arrangement of the flight controls, you can go into the app and modify the configuration to your liking.
This controller has utilizes the DJI Lightbridge link to connect directly to your smartphone. So for FPV monitoring of the drone flight, you have 720p video at 30 fps that can be used up to about 2 km.
The piloting application is available for both Android and Apple operating systems. The app features a readout to show how fast you are travelling, and a signal strength indicator between your controller and the drone. There is also a mini map that lets you track the position of your drone. The app allows calibration of the compass and drone gyros and provides a battery level indicator. For videos and stills, you can control all settings from the app. You can shoot still images while you are taking a video.
The app allows for numerous camera settings. You can pick if you want the still images in JPEG or in the raw native format. For the video quality settings, you have options for white balance, and setting the contrast and saturation levels. There are four different video modes: 2 x 4K options, and 1920 x 1080p and 720 P options.
The controller is roughly similar to previous versions, with two main sticks and a clamp to hold a tablet — It is quite possible to make use of your iPad Mini without a problem — which acts as the display for the drone’s camera via the DJI Pilot app. There are small, fold-down brackets to hold a smartphone, with the app optimised for use with the iPhone 5S , 6 and 6 Plus . It is easier, however, to view the footage and use the app’s small on-screen buttons on the the tablet’s larger screen. Android device support is thin, with just the Samsung Galaxy S5 and Note 3 , Sony Xperia Z3 , Google Nexus 7 II , Google Nexus 9 , Xiaomi Mi 3 and ZTE Nubia Z7 mini listed.
On each top corner of the controller are buttons for starting and stopping recording and quickly changing camera settings like the exposure and angle of view. Using these physical controls is much easier than poking at the tiny on-screen controls while the drone is airborne.
DJI Phantom 3 Professional: Flight Performance
This drone is rather easy to learn how to fly. Taking this for a spin for 15 minutes in an open area will give you the proper feel for the basics of flight. The drone features good accelerations, as well as good deceleration for avoiding any potential obstacles. The drone does correct for wind, so it can handle slight winds.
This drone is a very stable imaging platform, and provides for smooth and stable flight that result in amazing captured imagery. To aid in stability, the drone has an optical flow sensor which essentially another small camera that detects patterns to lock onto in order to stabilize its xy position. This allows for very stable hovering over a fixed position. There are also ultrasonic sensors that measure the distance from the drone to the ground, providing for more accurate elevation estimation.
This drone has an improved GPS internal processor allowing for quick acquisition of a GPS signal lock. This GPS also works with the Russian as a well as the standard GPS satellites, allowing for faster and more reliable satellite signals for position determination.
DJI Phantom 3 Professional: Value for Money & Guarantee
With the DJI PHANTOM 3 PROFESSIONAL, you get more than what you pay for because of its ability to satisfy users even more than what their wallet could vomit.
DJI Phantom 3 Professional: Additional Features
Worry-Free Autopilot’ and Navigation
One key take off/land
The Q500 4K Typhoon is bundled with the ST10+ Personal Ground Station, a 10-channel, 2.4 GHz transmitter and 5.8 GHz video receiver rolled into one hand-held unit. In addition to traditional RC joysticks to pilot the quadcopter, there is a built-in Android mobile device which boasts a 5.5″ touchscreen – a bump from the original ST10, which has a 4.5″ screen. It allows you to view an FPV (first-person view) video image from the camera along with telemetry data superimposed, as well as access settings not available through normal transmitter.
As part of the RTF bundle, if features two 5400mAh flight batteries, providing up to 25 minutes flying each per charge – depending on wind-resistance and other factors. Additionally, the bundle features an aluminum case with removable trolley to safely store and transport the Q500+ and accessories in.
CGO3-GB 4K Camera with 3-Axis Gimbal:The included CGO3-GB combines a 12-megapixel, 4K camera and a 3-axis brushless gimbal into a single unit designed to capture stabilized aerial video and still images. In addition to 4K, the camera can shoot 1080p at 120 fps for slow-motion as well as 60p, 50p, and 48p. A built-in microphone enables audio recording and can be turned on or off via the ST10+ or mobile app. Photos can be captured in JPEG or DNG RAW and it is possible to snap photos while recording video
For live view and remote operation, the camera features an integrated 5.8 GHz Wi-Fi downlink that enables operation and viewing from the 5.5″ touchscreen on the ST10+ Personal Ground Station. You can also pair with a mobile device using the free mobile app – available at Google Play and iTunes app stores. The app or ST10+ offer control over resolution, white balance, ISO, and shutter speed. A smartphone holder that mounts on the ST10+ is included
The camera features a wide angle 130-degree FOV lens. While the gimbal that supports it features a control angle accuracy of ±0.02°. High quality video and stills are recorded to a microSD card up to 128GB in size. Low quality, upload-friendly versions can be saved onto a mobile device
ST10+ Transmitter/Personal Ground Station:Transmitter (hand-held radio controller) and ground station system are combined into one device with the 10-channel ST10+. It features a 2.4 GHz transmitter for joystick operation of the quadcopter. In addition, there is a 5.8 GHz-range receiver for the video feed from the camera plus telemetry data. Updates over the original ST10 include a brighter touchscreen that is now 5.5″ in size. The screen plus embedded Android OS enable you to control the camera as well as view a live feed from it, complete with telemetry data overlaid (OSD)
Flight Control Features:The Q500 4K Typhoon flight computer has access to a database of published FAA no-fly areas – such as zones near airports. Additionally, the maximum flight altitude can be locked to remain below 400′ AGL (above ground level) for further compliance
Designed for beginners, this mode uses GPS to establish a 26′ “SAFE Circle” around the pilot. Stick relativity is maintained, meaning the aircraft will move in the same direction the stick is pressed is relative to the pilot, regardless of which way the quadcopter’s actual “nose” is pointing. A “virtual barrier” imposes maximum radius of 300′, help to ensure visual with the quadcopter is always maintained
This mode is optimized for experienced pilots using the Q500 4K Typhoon for aerial photography. It provides more control and steeper bank and pitch angles, helping open your work up to a greater variety of possible shots
This safety feature can be activated at any time with the simple flip of a switch on the ST10+. When activated, the Q500 4K Typhoon will automatically return to its “home point” and land within a 10′ circle of where it took off. If for whatever reason the transmitter signal is lost, Return Home will take over and fly the Q500 4K Typhoon back to the home point until it lands or the signal is restored
Note: Proper GPS calibration is required to ensure this feature works correctly
Includes CGO3 SteadyGrip
Transform the CGO3-GB camera and gimbal into a handheld, stabilized mini-rig with the included CGO3 SteadyGrip. It features a smartphone holder for iOS and Android devices that have screens up to 6.4″ so that you can use the app to monitor a live feed and operate camera settings (5.8 GHz Wi-Fi support on the mobile devices is required). The gimbal slides on with rail attachment for quick setup and draws its power from six AA batteries that are housed in the base (batteries available separately). A pitch control roller on the top of the handgrip allows you to manually adjust camera tilt while shooting
The quadcopter comes ready-to-fly, meaning that a transmitter (radio controller), flight battery, battery charger, propellers, 64GB microSD card, and hard transit case come included (mobile device available separately).
4K / 12MP Gimbal-Stabilized Camera
The X-Star camera, with its Sony Exmor R sensor, captures 4K video at 30 fps, 2.7K at 60 fps, 1080p at 120 fps, and – for super slow motion – 720p at 240 fps. Video is recorded in full quality to a microSD card in-camera. Additionally, a live HD feed is beamed to the ground-end for monitoring and reference recording on a mobile device
The X-Star camera takes 12MP still photos in JPEG, RAW, or RAW & JPEG. Available photo modes include Single Shot, Burst, AEB, Bracketed Frames, and Time-Lapse
The lens features an FOV of 108° with the camera in its widest image mode. This provides a wide field-of-view that encompasses a large part of the scene in front of the lens while not delving into fisheye territory
The camera is mounted via a 3-axis gimbal. This provides stabilization and allows independent camera movement relative to the quadcopter. The gimbal can be detached to store separately from the aircraft
Radio Controller and Mobile App
Transmitter (Radio Controller)
A pre-bound transmitter is included with the X-Star Premium. In addition to sticks for basic throttle and movement controls, function keys are provided to activate assisted flight modes or snap a shot with the camera. An integrated LCD screen provides vital flight data
The StarLink mobile app allows you to gain additional functionality as well as view a live 720p HD image from the camera. With it, you can adjust camera settings, monitor in-flight telemetry data, access advanced flight control settings, and utilize the Smart Pre-flight Check. A mobile device holder that attaches to the transmitter is included (compatible mobile device available separately)
Helps keep the quadcopter on course, even if affected by wind or in the presence of magnetic interference that can throw off the compass
- Starpoint Positioning System
The Starpoint Positioning System lets X-Star Premium stay accurately positioned at low altitudes, even without GPS
- GPS Enabled
Works with both GPS and GLONASS for precise position when used outdoors
- Flight Control Modes
Computer-assisted flight modes include Follow, Orbit, Waypoints, and GoHome
- Beginner Mode
Beginner Mode sets strict bounds on aircraft performance to avoid mistakes
Flying Experience (Tаking Control/How it works)
Fly with absolute freedom and confidence, knowing your Phantom 3 Standard will return to you at the press of a button. Built-in GPS records your Phantom’s takeoff point and remembers it as you fly. Then at your command, or if the control signal is ever lost, your Phantom comes back to you instantly. Your Phantom 3 Standard stays stable and under your control at all times during flight. After takeoff, it automatically hovers in place, waiting for your command. It then effortlessly changes altitude or direction at the flick of a finger. When you want it to stop, it again pauses and hovers, waiting for your next instruction. When you stop telling it to move, the Phantom 3 Standard hovers perfectly in place, holding both position and altitude. It waits for you to give it instructions. This means all you need to think about is where you want to fly. Throughout each flight, your Phantom 3 Standard sends its position to a live GPS map on your mobile device. Use this map to see right where it is, know which direction it is facing, and guide it back to you in an instant.
Because the Phantom knows where it is and where you are, it can calculate how much longer it can continue flying. It will send you a reminder to land when the battery runs low, and it can automatically come home and land when needed. Four bright, large LED lights on each arm of the Phantom 3 Standard light up as you fly. So at a glance, you know which direction your Phantom is facing and its current status.
Fly for up to 25 minutes on a single charge. The patented DJI Intelligent Flight Battery continuously tells you exactly how long you can continue flying, based on how far and at what altitude you are, and it alerts you when it’s time to head back. This information is streamed live to the GO app on your mobile device. Recharging is quick and easy, and bright LED indicators tell you current status and power level. A protective plastic housing helps prevent damage and contains intelligent sensors that make your battery worry-free while extending the life of your battery.
This drone is features excellent image quality, allowing up to 4K resolution video capture. It is quick to setup and very easy to learn how to fly. The stabilized gimbal platform provides for smooth flowing images with no jitter.
Getting started with the drone is incredibly easy. When you take it out of the box, just start charging the battery and the controller (a supplied lead charges both through one plug), and download the DJI Pilot app onto your iOS or Android device.
The DJI Phantom 3 has a lot of features for its given price point. This will easily meet your imaging needs for aerial photography. With its simple operation and great image quality, the DJI Phantom 3 Professional is one of the best ways to get into aerial videography.
